FABLOGIC I-500

This latest-generation system uses internal gaskets to provide a fully weather-sealed system with the visual aesthetics of open joint or rainscreen panel systems. No caulk or exterior gaskets are required.weather-sealed panels

  • Utilizes full-length interconnecting perimeter extrusions that reinforce the panel flanges and provide self-alignment of panels
  • Pre-finished integral extruded joinery
  • Optional joint sizes and accent colors
  • Can be rear insulated
  • High-performance system with guttering extrusions
  • Comprised of 4- or 6-mm composite panel
  • Lightweight construction
  • Complex and curved shapes
  • Recessed composite panel joint filler
  • Can be applied over a variety of substrates
  • FR core material available to meet NFPA 285 multi-story fire testing per IBC 2009
  • Lengths up to 21’
  • Widths up to 5’
  • Low maintenance
  • Solid plate skins are available as an alternative option to composite

I-500 Properties

Joint Size: ½” wide (13mm) Recessed 1”

Joint Material: Pre-finished Extruded Aluminum to Match or Compliment Panel Face

Wall Design: Internal Gasket, Weather-Tight

Testing: ASTM E 283-04: Test Method for Determining Rate of Airflow Through Exterior Windows, Curtain Walls and Doors by Uniform Static Air Pressure Difference, ASTM E 330-02: Test Method for Structural Performance of Exterior Windows, Curtain Walls and Doors by Uniform Static Air Pressure Difference, ASTM E 331-00: Test Method for Water Penetration of Exterior Windows, Curtain Walls and Doors by Uniform Static Air Pressure Difference. View Report
